Name: 2MP Marine PTZ Dome Camera
Brand: KAIDUNEX
SKU: MC500
Availability: InStock
Rating: 5 (1 reviews)

Description

Functional Positioning and Target Users for Marine Surveillance
The 2MP Marine PTZ Dome Camera is engineered specifically for maritime and offshore security professionals requiring reliable, high-precision visual monitoring in challenging environments. As a CCS type approval camera designed to meet stringent classification society approval standards, it is ideally suited for installation on commercial vessels, oil rigs, and port facilities. Its robust marine standard camera features ensure endurance against corrosive saltwater atmosphere and physical exposure, fulfilling operational demands for ship operators, maritime security teams, and marine safety supervisors who require real-time situational awareness and incident documentation in harsh marine conditions.

Technical Features and Measurable Specifications
This device incorporates a stainless steel 316L housing rated at IP68 for full waterproof and dust-tight protection, guaranteeing durability under continuous marine exposure. Its 2MP image sensor provides high-definition video clarity, while the 4x optical zoom facilitates detailed observation of distant or expansive deck areas. Infrared night vision extends surveillance capabilities up to 20 meters in low-light or nighttime conditions. Supporting dual power options, DC12V and Power over Ethernet (PoE), it allows flexible electrical integration compliant with marine CCTV cameras system solutions. The PTZ (pan-tilt-zoom) mechanism enables comprehensive viewing angles controlled remotely, optimizing monitoring efficiency onboard vessels or port infrastructure.

Industry Applications and Real-World Value in Maritime Operations
Widely applied in marine environments, this anti-corrosion camera addresses the critical need for continuous vessel surface monitoring, cargo deck inspection, and port security management. It enhances hazard detection and perimeter security by integrating with onboard safety systems to support compliance with maritime regulatory frameworks. This camera’s marine-grade corrosion resistance and rigorous structural design ensure longevity and minimal maintenance costs, thus improving life cycle ROI for operators. Its integration flexibility supports surveillance across offshore platforms, coastal boundaries, and expansive open water territories, enabling effective incident investigation and maritime situational awareness critical for operational safety.

Product Advantages

Design and Structural Integration Excellence
The 2MP Marine PTZ Dome Camera features a precision-engineered stainless steel 316L enclosure that provides superior anti-corrosion performance essential for marine environments exposed to salt spray and humidity. Designed to fulfill classification society approval requirements, it supports seamless integration into existing marine CCTV cameras system solutions, facilitating modular scalability of surveillance infrastructure. The compact dome form factor with IP68 ingress protection ensures resilience against water and dust intrusion, while the PTZ mechanism’s mechanical reliability guarantees sustained operation under dynamic maritime conditions, reducing downtime risks for security camera suppliers managing fleet or port surveillance systems.

Performance and Operational Value for Marine Security
This solution offers enhanced operational utility with high-resolution imaging combined with a 4x optical zoom and infrared capabilities, allowing detailed monitoring regardless of lighting conditions. The option for Power over Ethernet simplifies installation and reduces cabling complexity, critical for onboard retrofit projects. Security personnel benefit from real-time panoramic controls and zoom precision to rapidly identify potential threats or anomalies, improving response times. This marine standard camera delivers consistent performance aligned with CCS type approval standards, ensuring equipment complies with international marine safety and security regulations, thereby reducing compliance risk and enhancing asset protection value proposition.

Material	Stainless Steel 316L
Protection Class	IP68
Temp.range min	-40℃
Temp.range max	+70℃
Video	IP
Operational Areas	Outdoor
Mounting	Wall mounted,ceiling installation
Surface	Powder coating
IR Range	20m
Field of View	H:100.5°-32.6°,V:52.8°-18.3°,D:120.2°-37.5°
Resolution	2MP,4MP etc
Focal Length	2.8-12mm,4x Optical zoom
Image Sensor	1/2.8”Progressive Scan CMOS
Image Sensor	Color:0.005lux@(F1.5,AGC ON);
Min.illumination	B/W:0.001lux@(F1.5,AGC ON)
Min.illumination	Anti-Flicker,heartbeat,password
Functions	protection,Privacy mask,watermark
Voltage	DC12V/POE power optional
Weight	≤4kg
Dimensions(LWH)	182182135mm
Certificates	CCS Type Approval;BS EN62676-1-1-2014,CE-EN60945

Service

You can have the product replaced within 7 days due to quality problem and the quality guarantee period for this product is one year.
You can also get the favorable promotions.
In the following conditions the product is not considered within the quality guaranteescope:
- Client cannot bring forth the quality guarantee card and invoice or receipt of purchasing;
- Improper service conditions,such as unmatched power,ambient temperature,humidity or lightingcaused malfunction;
- Malfunction caused by accident,negligence,disaster incorrect operation or network attack;
- Malfunction or damage in installation,repair,modification or dismantle caused by unauthorizedpersonnel;
- Out of guarantee period.
If you have any dissent on technical service provided by distributor,please lodge acomplaint to the customer's service center of Kaidun.
The quality guarantee card will be validated only after it's stamped by the after-service provider.

Use Scenarios

Surveillance Role in Maritime Vessel Safety Management
Within the maritime transport industry, the 2MP Marine PTZ Dome Camera serves as an integral component of onboard surveillance, tasked with continuous monitoring of vessel decks, engine rooms, and cargo areas. Its corrosion-resistant build and marine standard camera certification allow dependable operation in saltwater and humid shipboard environments. The camera’s PTZ control facilitates versatile viewing angles for security teams, enabling proactive detection of unauthorized personnel or safety hazards. Integration with shipboard safety systems leverages live and recorded video data for operational oversight, incident review, and compliance with maritime safety regulations, supporting effective risk management in vessel operations.

Port Security and Coastal Facility Monitoring Applications
In port and coastal infrastructures, this anti-corrosion camera provides comprehensive CCTV coverage to monitor berthing areas, cargo handling, and perimeter zones. The robust 316L stainless steel casing withstands corrosive maritime climates, while the CCS type approval confirms adherence to classification society standards vital for secure port operations. Its infrared night vision capability extends surveillance capability after dark, enhancing detection of intrusions or irregular activities. The camera integrates smoothly with centralized marine cctv cameras system solutions, enabling port authorities to coordinate security workflows efficiently and maintain high operational safety standards, critical for maritime infrastructure protection and regulatory compliance.

FAQ

What materials ensure the 2MP Marine PTZ Dome Camera’s resistance to harsh marine conditions?
This camera features a stainless steel 316L enclosure, providing robust anti-corrosion camera protection against saltwater and moisture. Its IP68 waterproof rating guarantees durability in extreme maritime environments, suitable for long-term marine surveillance applications.

Can the 2MP Marine PTZ Dome Camera be customized for specific industrial applications?
Kaidun offers tailored solutions considering site-specific requirements. The camera’s modular design supports integration with various safety systems, meeting the needs of different sectors including offshore, shipbuilding, and chemical plants, ensuring compliance with marine CCTV cameras system solutions.

What installation options are available for the 2MP Marine PTZ Dome Camera?
Installation is flexible with support for DC12V power or Power over Ethernet (PoE). Its PTZ control allows versatile mounting positions on marine vessels or offshore platforms, facilitating comprehensive 360-degree surveillance coverage and operational convenience.

How does Kaidun ensure logistics and after-sales support for its marine surveillance cameras?
Kaidun leverages its global sales network to provide timely delivery and post-installation services. Their expertise with security camera supplier standards ensures reliable maintenance advice and technical support, helping businesses maintain uninterrupted marine safety operations.
