Functional Positioning for Hazardous Surveillance Deployments
Designed specifically for high-risk areas, this explosion proof camera integrates within broader industrial camera systems aimed at users requiring durable and compliant equipment. It caters to sectors with stringent safety standards including petrochemical plants and offshore facilities. The camera supports installation versatility with multiple power inputs, ensuring adaptable deployment. This security surveillance camera reduces risk factors by providing constant monitoring in hazardous zones while maintaining operational safety protocols, effectively fulfilling industrial surveillance cameras mandates for explosion protection and environmental resilience.
Technical Specifications That Ensure Precision and Reliability
At its core, the camera features a 4MP resolution sensor paired with an exceptional 22x optical zoom range (5.2–114.4 mm), enabling detailed image capture from extended distances. The inclusion of infrared illumination, with coverage extending to 150 meters supported by a wiper system, facilitates clear visibility under low-light and adverse weather conditions. Constructed of stainless steel 316L with IP68/IP66 ratings, it withstands corrosive and extreme temperature environments (-40°C to +60°C). Embedded AI ISP technology delivers noise reduction and enhanced dynamic range, making it a critical component of effective industrial camera systems.
Industry Applications Emphasizing Safety and Operational Continuity
This explosion proof camera is integral for applications in chemical plants, oil rigs, maritime ports, and other harsh environmental conditions. Its anti-corrosion features and durable build allow it to address perimeter security and remote inspection needs where conventional cameras fail. By interfacing seamlessly with established industrial surveillance cameras frameworks and protocols like ONVIF, it enables comprehensive security surveillance camera solutions that enhance situational awareness and compliance with safety standards, thereby directly supporting operational continuity and asset protection.
Robust Design and System Integration for Hazardous Environments
The camera’s explosion proof certification and stainless steel 316L housing ensure mechanical integrity against impact, corrosion, and extreme environmental factors. Its compact dimensions combined with multiple mounting options facilitate flexible deployment within complex industrial camera system architectures. The protective construction complies with BS EN62676-1-1-2014 standards, guaranteeing reliable operation in Ex zones. Additionally, the device’s diverse power supply compatibility optimizes integration into existing wiring infrastructures common in industrial surveillance cameras setups.
Enhanced Performance and Operational Usability
Equipped with superior optics offering 22x zoom and significant IR range, the camera provides stable, high-quality video output critical for real-time analysis. The wiper feature maintains lens clarity in rain, dust, and other adverse weather conditions, reducing maintenance needs. From a user perspective, this security surveillance camera supports diverse power options simplifying installation logistics, while its AI-powered image processing delivers clearer surveillance footage, thereby maximizing the return on investment through reduced downtime and improved monitoring accuracy.
|
Type |
KDH-EX-VL422IRW01 |
|
Material |
Stainless Steel 316L |
|
Protection Class |
IP68 |
|
Temp.range min |
-40℃ |
|
Temp.range max |
+60℃ |
|
Video |
IP |
|
Operational Areas |
Outdoor |
|
Mounting |
Wall mounted,column etc |
|
Wiper/IR |
Wiper/IR |
|
Infrared Distance |
100-150m |
|
Resolution |
4MP(2560*1440) |
|
Zoom |
5.2~114.4mm,22x optical zoom |
|
Image Sensor |
1/2.7’’Progressive scan CMOS |
|
Min.illumination |
Color:0.003lux@(F1.65,AGC ON),Black and white:0.002lux@(F1.65,AGC ON) |
|
Functions |
Motion detection,occlusion detection,sound detection,alarm input,and alarm out put |
|
Voltage |
DC12V/POE/DC24V/AC24V/POE+/AC100-240V power optional |
|
Weight |
≤8KG |
|
Dimensions(L*W*H) |
428*183*241mm |
|
Certificates |
BS EN62676-1-1-2014 |
|
Explosion Proof Mark |
Ex ll 2G Ex db op is IIC T6 Gb II 2D Ex tb op is IIIC T80℃ Db IP68 IP66 |
What materials are used in your explosion proof camera products?
Our explosion proof cameras use high-grade stainless steel 316L for its excellent anti-corrosion and durable properties, suited for harsh industrial conditions. This ensures reliable protection and long service life in industrial camera system applications exposed to corrosive or explosive environments.
Can you customize your security surveillance camera solutions?
Yes, we warmly accept ODM and OEM requests for our security surveillance camera products. We can customize packaging, branding, logos, and even develop new molds to fit unique project needs, ensuring tailored solutions that meet your specific industrial surveillance requirements.
How should I install the 4MP 22X Explosion Proof Anti-Corrosion IR Bullet IP Camera?
Our camera supports flexible outdoor installation methods including wall mounting and column installation. It is designed for heavy-duty use with multiple power options (DC12V/POE/DC24V/AC24V/POE+/AC100-240V), allowing integration into a variety of industrial surveillance cameras networks and systems.
What shipping methods are available for ordering your industrial surveillance cameras?
We partner with international express couriers such as DHL, UPS, FedEx, TNT, and EMS to deliver orders promptly worldwide. We aim to ensure our clients receive their industrial camera system equipment quickly and securely for uninterrupted surveillance deployment.
