The 4MP 22X Explosion Proof Anti-Corrosion PTZ IP Camera from trusted explosion proof camera manufacturers delivers durable, high-resolution surveillance with advanced zoom and AI features, suited for industrial cameras and security camera vendors focused on hazardous environments.
Targeted Industrial Surveillance Solutions
Designed for demanding industrial and hazardous environment surveillance, this 4MP 22X Explosion Proof Anti-Corrosion PTZ IP Camera caters to facilities requiring reliable, explosion-proof monitoring. Intended primarily for system integrators, security camera vendors, and industrial operators in sectors such as offshore oil, chemical plants, and maritime installations, the device ensures compliant and continuous operation. The rugged stainless steel housing and extensive video analytics capability meet the stringent requirements of surveillance cameras for business environments exposed to extreme conditions, providing peace of mind to procurement managers and engineers seeking long-term operational safety and efficiency.
Advanced Imaging with Precision Control
Equipped with a 1/2.7" CMOS sensor and 22x optical zoom, this industrial camera delivers superior image quality in resolutions up to 4MP with frame rates of 30fps. Its 120 dB wide dynamic range and adaptive fog-layer technology enable effective visualization in challenging lighting conditions, including low-light and starlight scenarios. The device integrates intelligent features such as AI-based face and human detection, automatic tracking, and multi-stream video support (H.265/H.264/MJPEG), optimizing bandwidth and storage. Robust IP68 ingress protection and IK08 impact resistance, along with certified explosion-proof standards (ATEX, IECEx), ensure reliable functionality under corrosive and hazardous environments, addressing key concerns of explosion proof camera manufacturers.
Comprehensive Industry Application and Compliance
This camera solution is engineered for use in industrial sectors like oil and gas, marine ports, chemical refineries, and offshore platforms, providing vital surveillance in environments vulnerable to explosive atmospheres and corrosive agents. Its compliance with ONVIF and GB/T28181 protocols facilitates integration within complex security systems, essential for security camera vendors deploying surveillance cameras for business operations with strict industry standards. By enhancing perimeter control, asset protection, and operational safety, the product provides measurable cybersecurity and safety ROI for industrial facilities seeking to mitigate risk while maintaining regulatory compliance.
Product Advantages
Structural and Design Integration Advantages
The camera features an explosion-proof stainless steel 316L housing designed by industry-leading explosion proof camera manufacturers to withstand extreme environmental challenges such as corrosive chemicals and physical impacts (IK08). The modular design incorporates a sealed 36-pinFFC interface supporting power, network, and auxiliary input/output, enabling multi-platform integration with legacy and new industrial cameras. IP68-rated ingress protection combined with surge protection (2 kV) ensures resilience in harsh conditions frequently encountered by surveillance cameras for business. The PTZ mechanism delivers full 360° horizontal and ±90° vertical rotation, providing comprehensive situational awareness within a compact footprint, suited for complex industrial network environments.
Performance and User-Centered Operation Benefits
Leveraging advanced AIISP noise reduction and adaptive fog compensation, the camera maintains consistent image clarity enabling precise identification under diverse conditions, thereby reducing false alarms and operator fatigue. The main stream and dual auxiliary streams support dynamic bandwidth allocation, enhancing network efficiency for industrial surveillance systems. Intelligent features including face recognition, vehicle/pedestrian classification, and cross-boundary detection improve automation and reduce manual monitoring load, boosting operational productivity for cctv camera suppliers and security camera vendors. The camera’s wide operating temperature range (-40°C to +60°C) and certified explosion-proof safety ratings ensure dependable performance without compromise, delivering value through reduced downtime and compliance assurance.
| Camera | |
| Image device | 1/2.7"Inch line by line scan 4MP CMOS image sensor |
| Optical double | 22X |
| Focal distance | Electric and dynamic zoom,5.2~114.4mm |
| Field of View (H) | 3.49°~60.47° |
| Field of View (V) | 1.97°~36.30° |
| Field of View (D) | 4.12°~74.38° |
| Iris diaphragm | F1.6(W)~F3.6(T) |
| Shutter | Automatic /manual,1~1/100000s |
| Through the fog | Adaptive fog |
| Noise-signal ratio | >56DB |
| Wide Dynamic | 120DB |
| Minimal illumination | 0.003Lux(F1.65,AGC ON,color),0.002Lux(F1.65,AG C ON,black and white) |
| Switch the mode day and night | Automatic,day,night,switching quantity control |
| 3D positioning | Support |
| Anti-shake | Support |
| Detection Distance | 90-1500m |
| Observe Distance | 40-570m |
| Video frequency | |
| Video coding | H.265、H.264、MJPE G |
| Maximum frame rate | 30 Frames |
| Video stream | Main code stream:2688*1520,2560*1440,2304*1296,1920*1080,1280*720(720P),720 *576 (D1),640*360,704*288(2 CIF),352*288(CIF);Auxiliary code stream:1920*1080,1280*720(720P),720*576 (D1),640*360,704*288(2 CIF),352*288(CIF)Third stream:720*576(D1),640*360,704*288(2 CIF),352*288(CIF) |
| Video code rate | 128Kbps~16Mbps |
| OSD | Time,cloud head coordinates,multiplier,preset bit,serial port OSD,number of peoplestatistics,network port OSD,picture OSD,environment volume,device longitude and latitudesittingStandard et al |
| Regional Enhancement (ROI) | Eight areas |
| Privacy cover | Black style,Marseille,gram style:8 single scenes,24 multiple scenes |
| Screenshot | Regular grasp,periodic grasp,cruise preset bit grasp,manual grasp |
| Grasp the map at the maximum resolution | 2688*1520 |
| Audio frequency | |
| Audio encoding format | .7G 11U、G.711A |
| Audio sampling rate | G.711U、G.711A:8KHz /16K Hz |
| Memory | |
| Front end storage | Micro SD,up to 256GB |
| Intelligence | |
| Face detection | Support effect priority,speed priority,cycle preferred three face snap preferred mode,support face Angle filtering;Support human face,human body capture,support human face attribute extractionFace attributes:gender,age,wearing glasses,wearing masks,hat style,hat color |
| Peripheral cloth defense | Support cross-boundary detection,regional invasion,entry area and leaving area;Support motor vehicles,non-motor vehicles,pedestrian target classification detection capture and distribution |
| Number of statistics | Statistics of human flow:support the statistics of total number,number of entering and number of leaving,support the three-level alarm of the number of stranded,and clear the statistics of the number of support;Personnel density detection:to support the three-level alarm of personnel density |
| Autotracking | It supports the classification and tracking of motor vehicles,non-motor vehicles and pedestrian targets in the screen,and automatically returns to the original position after reaching the preset tracking time |
| Smart Function | |
| Common event | Motion detection,occlusion detection,sound detection,alarm input,and alarm out put |
| Network | |
| Networking protocol | L2TP、IPv4、IPv6、IGMP、ICMP、ARP、TCP、UDP、DHCP、RTP、RTSP、RTMP、DNS、DDN S、NTP 、FTP 、UPnP 、HTTP 、SNMP 、SIP |
| Compatible access | ONVIF Profile G 、Profile T 、Profile S、GB/T28181、GA/T 1400、API |
| Cache supplement | Support SD card broken network cache supplementary record |
| Interface features | |
| Interface form | 36PinFFC(including network port,power supply,serial port UART_1,serial port UART_2,Alarm In /0ut,Audio In /0ut) |
| General | |
| Power | POE+/AC100V-240V etc optional,≤50W (The maximum power supply distance of POE+ is 80m.) |
| Dimensions(L*W*H) | 436*296*406mm |
| Net Weight | ≤26kg |
| Material | Stainless Steel 316L |
| Working Environment | -40℃~60℃,Humidity:≤100%RH(non-condensing) |
| Strorage Environment | -40℃~60℃,Humidity:s100%RH(non-condensing) |
| Surge Protection | 2KV |
| Ingress Protection | IP68 |
| Inlet Hole Specification | 1 Entry hole G3/4 |
| Installation Method | Wall or column platform installation |
| PTZ | |
| Rotation Angel | Horizontal:0°-360° Vertical:-90°-+90° |
| Approved | |
| Protectior | IK08(IEC 62262:IP68(IEC 60529-2013) |
| Explosion protection |
ATEX:ll 2G Ex db lIC T6 Gb/ll 2D Ex tb IIIC T80℃Db IP68 IECEx:Ex db lIC T6 Gb/Ex tblIIC T80C Db IP68;For explosive gas atmospheres,the maximum surface temperature is 85℃.Flammable dust atmosphere with a maximum surface temperature of 8°℃;IC:Explosive gas atmospheres other than mine fires;Explosive gas mixture environment:Sector 1,Sector 2,Sector 21,Sector 22. |
| Verfication to | BS EN62676-1-1-2014- Video surveillance systems for use in security applications |
Service
Use Scenarios
Explosion-Proof Surveillance in Offshore Oil Rigs
Offshore oil platforms operate in volatile environments where the risk of ignition necessitates certified explosion-proof monitoring solutions. This PTZ IP camera, sourced from reputable explosion proof camera manufacturers, is instrumental in providing real-time surveillance with corrosion-resistant stainless steel housing that stands up to salt spray and harsh weather. It supports continuous auto-tracking of personnel and equipment, integrating with broader industrial cameras frameworks for proactive incident response and safety compliance. The device’s adherence to ATEX and IECEx standards ensures legal conformity, while its advanced zoom and night vision capabilities facilitate 24/7 monitoring critical to offshore operational integrity and environmental protection.
Secure Perimeter Monitoring for Chemical Plants
In chemical processing facilities, the need for robust, anti-corrosion surveillance cameras is paramount to safeguard against unauthorized access and operational incidents. The 4MP 22X PTZ camera functions as a core security component within surveillance cameras for business systems tailored to industrial risk environments. Its multi-stream video capability allows integration with SCADA and security management platforms, enabling detailed situational awareness under adverse conditions such as fog and corrosive atmospheres. The camera’s AI detection features streamline threat identification, while its IP68 rating and stainless steel construction provide durability against chemical exposure, ensuring continuous operation aligned with industry safety and environmental compliance standards.
What materials are used in your explosion proof camera housings?
Our explosion proof cameras feature stainless steel 316L housings known for superior corrosion resistance and durability under harsh industrial conditions. This material, combined with specialized engineering, meets stringent standards required by industrial cameras deployed in marine and chemical environments.
Can you customize the 4MP 22X PTZ IP Camera to fit specific project requirements?
Yes, we provide ODM and OEM services for our customers. We can customize features such as packaging, logos, and even hardware specifications to meet your project’s needs. As a reputable security camera vendor, we tailor solutions to align with your operational criteria and environmental demands.
What installation support do you offer for your explosion proof surveillance cameras?
We provide detailed technical documentation and guidance to assist with the installation of our explosion-proof and anti-corrosion cameras. Our teams are available for consulting to ensure the equipment integrates seamlessly with your existing surveillance infrastructure from qualified CCTV camera suppliers.
How do you handle shipping and delivery for large industrial orders?
We partner with reliable international express couriers including DHL, FedEx, UPS, and TNT to ensure timely delivery. Our logistics expertise helps expedite shipping, reducing downtime on your project and supporting your operational timelines efficiently.
