The 4MP 22X Explosion-Proof Anti-Corrosion PTZ Dome IP Camera offers robust surveillance for hazardous environments, combining advanced imaging, corrosion resistance, and AI analytics from leading explosion proof camera manufacturers. Ideal for industrial sites requiring precise monitoring with reliable commercial surveillance cameras.
Optimized Surveillance for Challenging Industrial Environments
Designed for critical security infrastructure, this 4MP 22X Explosion-Proof Anti-Corrosion PTZ Dome IP Camera meets the rigorous demands of hazardous operational sites. Target users include engineers and security system planners in petrochemical, offshore, and chemical processing industries requiring explosion proof camera manufacturers’ certified equipment. The camera’s stainless steel 316L housing and IP68 ingress protection ensure longevity amid corrosive atmospheres and extreme temperatures, addressing both safety requirements and operational dependability needed by commercial surveillance cameras deployed in heavy industry sectors.
Advanced Imaging Technology and Precision Optics
This security surveillance camera integrates a high-resolution 4MP CMOS sensor with a 22x optical zoom and adaptive focus system, enabling detailed long-range monitoring up to 114.4mm focal length. Technical specifications include wide dynamic range of 120 dB, Starlight low-light performance down to 0.003Lux, and AI-driven features such as ROI enhancement, real-time people and vehicle detection, and intelligent auto-tracking. The camera supports multiple video encoding formats (H.265/H.264/MJPEG) with up to 30fps at 2688x1520 resolution, offering efficient bandwidth management essential for advanced security camera manufacturers cctv supplier solutions integrated into complex surveillance networks.
Sector-Specific Application and Operational Benefits
This explosion-proof PTZ camera fulfills critical roles in industries ranging from maritime offshore platforms to natural gas extraction facilities. Its corrosion-resistant, explosion-proof construction complies with ATEX and IECEx standards, ensuring safe deployment in hazardous zones. The device’s 360° continuous rotation at speeds up to 300°/s combined with intelligent perimeter intrusion classification optimizes area security and threat response. Integration with ONVIF-compliant systems enhances interoperability, enabling facility-wide surveillance schemes to leverage this device as a core component among commercial surveillance cameras for comprehensive risk management and asset protection.
Product Advantages
Structural and Design Optimization for Harsh Conditions
Engineered with an IP68-rated stainless steel 316L housing, this explosion proof camera manufacturer product withstands corrosive marine atmospheres and extreme temperature ranges from -40°C to 60°C. Its IK08-rated impact resistance and surge protection to 2KV improve system resilience against industrial hazards. The modular design allows seamless integration with existing surveillance cameras infrastructure and supports flexible installation on poles or walls, aligning with specifications demanded by security camera manufacturers cctv supplier standards. Additionally, precision 360° pan and variable tilt angles support expansive coverage essential in commercial surveillance cameras utilized in large industrial premises.
Enhanced Operational Performance and User-Centric Features
Performance advantages include high-speed PTZ rotation for prompt target tracking and advanced AI analytics to reduce false alarms and enhance event detection accuracy. The camera provides multi-streaming capability to optimize network resource allocation while maintaining image fidelity. Automatic day/night switching, adaptive fog compensation, and built-in noise reduction algorithms ensure continuous operational clarity under varying environmental conditions. User-friendly configuration via ONVIF protocol and compatibility with major VMS platforms simplify system management, delivering measurable efficiency gains crucial for security surveillance camera deployment in demanding industrial applications.
| Camera | |
| Image device | 1/2.7"Inch line by line scan 4MP CMOS image sensor |
| Optical double | 22X |
| Focal distance | Electric and dynamic zoom,5.2~114.4mm |
| Field of View (H) | 3.49°~60.47° |
| Field of View (V) | 1.97°~36.30° |
| Field of View (D) | 4.12°~74.38° |
| Iris diaphragm | F1.6(W)~F3.6(T) |
| Shutter | Automatic /manual,1~1/100000s |
| Through the fog | Adaptive fog |
| Noise-signal ratio | >56DB |
| Wide Dynamic | 120DB |
| Minimal illumination | 0.003Lux(F1.65,AGC ON,color),0.002Lux(F1.65,AG C ON,black and white) |
| Switch the mode day and night | Automatic,day,night,switching quantity control |
| 3D positioning | Support |
| Anti-shake | Support |
| Detection Distance | 90-1500m |
| Observe Distance | 40-570m |
| Video frequency | |
| Video coding | H.265、H.264、MJPE G |
| Maximum frame rate | 30 Frames |
| Video stream | Main code stream:2688*1520,2560*1440,2304*1296,1920*1080,1280*720(720P),720 *576 (D1),640*360,704*288(2 CIF),352*288(CIF);Auxiliary code stream:1920*1080,1280*720(720P),720*576 (D1),640*360,704*288(2 CIF),352*288(CIF)Third stream:720*576(D1),640*360,704*288(2 CIF),352*288(CIF) |
| Video code rate | 128Kbps~16Mbps |
| OSD | Time,cloud head coordinates,multiplier,preset bit,serial port OSD,number of peoplestatistics,network port OSD,picture OSD,environment volume,device longitude and latitudesittingStandard et al |
| Regional Enhancement (ROI) | Eight areas |
| Privacy cover | Black style,Marseille,gram style:8 single scenes,24 multiple scenes |
| Screenshot | Regular grasp,periodic grasp,cruise preset bit grasp,manual grasp |
| Grasp the map at the maximum resolution | 2688*1520 |
| Audio frequency | |
| Audio encoding format | .7G 11U、G.711A |
| Audio sampling rate | G.711U、G.711A:8KHz /16K Hz |
| Memory | |
| Front end storage | Micro SD,up to 256GB |
| Intelligence | |
| Face detection | Support effect priority,speed priority,cycle preferred three face snap preferred mode,support face Angle filtering;Support human face,human body capture,support human face attribute extractionFace attributes:gender,age,wearing glasses,wearing masks,hat style,hat color |
| Peripheral cloth defense | Support cross-boundary detection,regional invasion,entry area and leaving area;Support motor vehicles,non-motor vehicles,pedestrian target classification detection capture and distribution |
| Number of statistics | Statistics of human flow:support the statistics of total number,number of entering and number of leaving,support the three-level alarm of the number of stranded,and clear the statistics of the number of support;Personnel density detection:to support the three-level alarm of personnel density |
| Autotracking | It supports the classification and tracking of motor vehicles,non-motor vehicles and pedestrian targets in the screen,and automatically returns to the original position after reaching the preset tracking time |
| Smart Function | |
| Common event | Motion detection,occlusion detection,sound detection,alarm input,and alarm out put |
| Network | |
| Networking protocol | L2TP、IPv4、IPv6、IGMP、ICMP、ARP、TCP、UDP、DHCP、RTP、RTSP、RTMP、DNS、DDN S、NTP 、FTP 、UPnP 、HTTP 、SNMP 、SIP |
| Compatible access | ONVIF Profile G 、Profile T 、Profile S、GB/T28181、GA/T 1400、API |
| Cache supplement | Support SD card broken network cache supplementary record |
| Interface features | |
| Interface form | 36PinFFC(including network port,power supply,serial port UART_1,serial port UART_2,Alarm In /0ut,Audio In /0ut) |
| PTZ | |
| Horizontal Rotation | 360°,0.1°/s～200°/s |
| Vertical Rotation | 0°～90°,0.1°/s～120°/s |
| Preset Position | 255,300°/s,±0.5° |
| General | |
| Power | AC110V-240V,≤40W |
| Dimensions(L*W*H) | 238*312*389mm |
| Net Weight | ≤12kg |
| Material | Stainless Steel 316L |
| Working Environment | -40℃~60℃,Humidity:≤100%RH(non-condensing) |
| Strorage Environment | -40℃~60℃,Humidity:s100%RH(non-condensing) |
| Surge Protection | 2KV |
| Ingress Protection | IP68 |
| Approved | |
| Protectior | IK08(IEC 62262:IP68(IEC 60529-2013) |
| Explosion protection |
ATEX:ll 2G Ex db lIC T6 Gb/ll 2D Ex tb IIIC T80℃Db IP68 IECEx:Ex db lIC T6 Gb/Ex tblIIC T80C Db IP68;For explosive gas atmospheres,the maximum surface temperature is 85℃.Flammable dust atmosphere with a maximum surface temperature of 8°℃;IC:Explosive gas atmospheres other than mine fires;Explosive gas mixture environment:Sector 1,Sector 2,Sector 21,Sector 22. |
| Verfication to | BS EN 62676-1-1-2014 - Video surveilance systems for use in security applications |
Use Scenarios
Hazardous Area Perimeter Monitoring in Petrochemical Plants
In petrochemical environments, where flammable gases and corrosive chemicals prevail, continuous monitoring is critical to prevent accidents. This explosion proof PTZ dome functions as a frontline security surveillance camera by delivering stable, high-resolution imagery with 22x optical zoom to inspect perimeter fences and access points. Its explosion-proof and anti-corrosion housing satisfies ATEX/IECEx compliance mandatory for hazardous zones, allowing uninterrupted surveillance through changing light and weather conditions. Integration with facility-wide alarm and control systems ensures real-time incident detection, empowering security operators with actionable intelligence for rapid intervention.
Marine Offshore Platform Security and Operational Oversight
Offshore oil rigs and marine installations require rugged surveillance cameras capable of enduring saltwater corrosion and severe weather. This security camera manufacturers cctv supplier model provides 360° rotation and continuous pan/tilt/zoom functionality to monitor vessel docks, loading operations, and restricted areas remotely. Its robust stainless steel construction and IP68 rating guarantee durability against marine corrosion. The camera’s advanced AI functions, including cross-border detection and auto-tracking, enable automated monitoring tasks within complex offshore security systems, supporting safe and efficient operation while reducing manual inspection demands.
FAQ
What materials are used in your explosion proof cameras for harsh environments?
Our explosion proof camera housings are made from high-grade stainless steel 316L and special engineering plastics, ensuring superior corrosion and high-temperature resistance. These materials meet the demands of industrial sites needing durable security surveillance cameras in challenging conditions.
Can I customize the surveillance camera features or branding when ordering?
Yes, we welcome OEM and ODM requests, offering tailored services including customized packaging, logos, branding, and even new molds. Our flexibility supports clients looking for specialized commercial surveillance cameras to meet specific project needs.
How do you ensure reliable installation and performance in hazardous locations?
We design our cameras with explosion-proof certification and corrosion resistance compliant with industry standards. The 360° continuous rotation with PTZ and IP68 ingress protection enables dependable use in hazardous zones, ensuring your security camera manufacturing investment performs securely.
What delivery options and payment methods do you support for international orders?
We collaborate with international express carriers like DHL, UPS, FedEx, TNT, and EMS to ensure timely delivery worldwide. Payment methods accepted include T/T, L/C, and Western Union, accommodating global buyers’ preferences for our explosion proof camera manufacturers products.
