Optimized Surveillance for High-Risk Environments
Designed explicitly for use in hazardous locations, this explosion proof camera targets industries requiring stringent safety controls, including chemical plants, oil rigs, and refineries. Its construction aligns with rigorous industrial surveillance cameras standards, allowing procurement teams and system integrators to deploy reliable monitoring solutions where conventional cameras fail. The bullet IP form factor facilitates versatile installation in outdoor, volatile settings, ensuring continuous capture critical for security surveillance cameras under extreme conditions. This surveillance camera system supports enterprises aiming to maintain compliance while enhancing operational safety through consistent visual oversight.
Precision Engineering with Advanced Technical Features
This industrial camera system integrates a 4MP progressive scan CMOS sensor with an extensive 33x optical zoom lens (4.5–148.5mm), delivering high-resolution video capable of identifying fine details at considerable distances. It supports robust IR illumination extending from 100 to 150 meters, ensuring effective low-light operation. The IP68/IP66-rated enclosure fabricated from 316L stainless steel ensures both explosion proof camera integrity and corrosion resistance, suitable for temperatures ranging from -40°C to +60°C. Additional features include high dynamic range (120 dB), adaptive algorithms for fog penetration and strong light suppression, plus AI-enabled motion and occlusion detection. Multi-protocol compatibility (ONVIF/GB/T28181) enables seamless integration into sophisticated surveillance camera systems.
Industrial Application Across Challenging Sectors
This explosion proof camera addresses surveillance challenges in sectors like petrochemical, offshore drilling, and heavy industry where safety and durability are paramount. Its ability to function reliably under harsh environmental conditions and extreme temperature fluctuations supports operational continuity and regulatory compliance. The surveillance camera system facilitates perimeter security, incident documentation, and routine inspection workflows within explosive atmospheres. Incorporating this industrial camera system into existing security infrastructure enhances monitoring reach while reducing maintenance and failure risks, providing measurable operational value for engineering and security management teams.
Product Advantages
Robust Structural and System Design for Harsh Conditions
The explosion proof camera features a ruggedized 316L stainless steel housing engineered to withstand corrosive elements and physical impact common in industrial settings. Certified to Ex II 2G Ex db op is IIC T6 Gb and II 2D Ex tb op is IIIC T80℃ Db explosion protection standards, it meets stringent safety requirements essential for hazardous areas. The modular design supports multiple power options, including POE, DC12V/24V, and AC24V/100-240V, facilitating flexible system integration into existing industrial surveillance cameras environments. Its IP68/IP66 ingress protection rating ensures dust tightness and water resistance, enhancing structural reliability and reducing downtime in security surveillance cameras installations.
Superior Performance and Operational Efficiency
Equipped with intelligent AI ISP features such as noise reduction, motion detection, and occlusion alerts, this industrial surveillance cameras model enhances situational awareness and reduces false alarms. The day/night switching with infrared illumination up to 150 meters ensures stable image quality 24/7, critical for continuous surveillance camera system operations. Easy compatibility with ONVIF and GB/T28181 protocols guarantees seamless integration and centralized management. Its long-range optical zoom enables precise target identification, improving ROI by reducing the need for multiple cameras while maintaining comprehensive coverage and user-friendly operation for monitoring personnel.
|
Type |
KDH-EX-VL433IR(W)01 |
|
Material |
Stainless Steel 316L |
|
Protection Class |
IP68 |
|
Temp.range min |
-40℃ |
|
Temp.range max |
+60℃ |
|
Video |
IP |
|
Operational Areas |
Outdoor |
|
Mounting |
Wall mounted,column etc |
|
Wiper/IR |
IR |
|
Infrared Distance |
100-150m |
|
Resolution |
4MP（2560*1440） |
|
Zoom |
4.5~148.5mm，33X optical zoom |
|
Image Sensor |
1/2.7’’Progressive scan CMOS |
|
Min.illumination |
Color:0.003lux@(F1.65,AGC ON),Black and white:0.002lux@(F1.65,AGC ON) |
|
Functions |
Motion detection,occlusion detection,sound detection,alarm input,and alarm output |
|
Voltage |
DC12V/POE/DC24V/AC24V/POE+/AC100-240V power optional |
|
Weight |
≤5KG |
|
Dimensions(L*W*H) |
386*145*241mm |
|
Certificates |
BS EN62676-1-1-2014 |
|
Explosion Proof Mark |
Ex ll 2G Ex db op is IIC T6 Gb II 2D Ex tb op is IIIC T80℃ Db IP68 IP66 |
What materials are used in your explosion proof camera housings?
Our explosion proof camera housings are made from stainless steel 316L, ensuring excellent anti-corrosion durability and strength. This makes our industrial camera systems suitable for harsh chemical, marine, and offshore environments requiring long-term reliability.
Can you customize industrial surveillance cameras to fit specific project needs?
Yes, we offer ODM and OEM services for all our industrial surveillance cameras. We can customize packaging, logos, branding, and even develop new molds based on your requirements to provide tailored surveillance camera systems that integrate seamlessly into your operations.
What installation options do you offer for the 4MP 33X IR bullet IP camera?
Our camera supports flexible mounting methods including wall mounting, columns, or other outdoor structures. Designed for industrial use, it is compatible with standard power options like POE, DC, and AC configurations to fit your existing industrial camera system setup.
How do you handle shipping and delivery for security surveillance cameras orders?
We partner with major international express carriers like DHL, UPS, FedEx, TNT, and EMS to ensure timely delivery of your security surveillance cameras. We aim to provide prompt global shipping while maintaining product integrity throughout transit.
