The 4MP 33X Explosion-proof Anti-corrosion IR PTZ IP Camera provides industrial surveillance with advanced zoom, low-light performance, and AI analytics. This security camera from leading manufacturers suits harsh environments and integrates as a reliable ptz ip camera.
Advanced Surveillance Solution for Hazardous Environments
Designed specifically for demanding industrial and hazardous areas, this explosion-proof and anti-corrosion ptz ip camera addresses the need for robust, continuous monitoring at chemical plants, offshore rigs, and refineries. System integrators and end users benefit from its rugged construction that ensures durability and safety compliance. The device effectively supports perimeter protection, asset monitoring, and personnel safety in inherently risky zones, making it a critical component for industrial security applications provided by reputable cctv suppliers and ptz cameras manufacturers.
Technical Excellence with High-Precision Optics and AI Analytics
The camera incorporates a 4MP CMOS image sensor paired with a self-developed 33x optical zoom lens covering a 4.5–148.5 mm focal length for detailed imaging from wide-angle to long-range views. It delivers a 120 dB wide dynamic range and ultra-low illumination sensitivity (0.003 lux color), ensuring clear images under extreme lighting conditions. Integrated AI ISP capabilities enable advanced functions such as face and human detection with attribute extraction, ROI-based monitoring, and perimeter security. It supports multiple video codecs (H.265/H.264/MJPEG) and standards like ONVIF and GB/T28181 for seamless compatibility, important for engineers specifying ptz cameras in complex security systems.
Industrial Deployment and Integration for Continuous Security
This security camera suits offshore and onshore industrial environments requiring explosion-proof monitoring and resistance to corrosive atmospheres. It supports microSD storage of up to 256GB for event recording and provides real-time analytics to improve security operations’ efficiency. The camera’s compliance with rigorous industry standards and its compatibility with existing networked video surveillance systems make it an indispensable asset for facilities focusing on long-term ROI and risk mitigation. Reliable delivery from a trusted cctv supplier guarantees integration flexibility within large-scale monitoring infrastructures.
Product Advantages
Robust Design and Integration Capabilities
The camera features a corrosion-resistant explosion-proof housing designed to withstand harsh chemical and marine environments, combining safety and durability critical for industrial use. Its modular design includes a 36-pin multifunctional interface accommodating network, power, audio, and alarm signals, facilitating integration into existing or custom security architectures. The device supports various protocols such as ONVIF profiles G/T/S and GB/T28181, enhancing interoperability typically expected from leading manufacturers of ptz ip cameras and cctv suppliers specializing in high-risk industrial segments.
Optimized Performance for Industrial Surveillance Efficiency
Performance-wise, this ptz cameras solution offers ultra-low-light imaging and automatic day/night switching with intelligent noise reduction to maintain image clarity in variable conditions. Its AI-driven analytics enable proactive threat detection, increasing situational awareness without requiring constant human supervision. End users benefit from bandwidth-efficient streaming standards and flexible storage options, contributing to operational cost savings and system scalability that professional buyers seek from specialized security cameras.
| Camera | |
| Image device | 1/2.7"inch line by line scan 4MP CMOS image sensor |
| Optical double | 33X |
| Focal distance | Electric and dynamic zoom,4.5~148.5mm |
| Iris diaphragm | F1.65 (W)~F4.7(T) |
| Field of View (H) | 51.4° ~ 2.5° |
| Field of View (V) | 30.3° ~ 1.4° |
| Field of View (D) | 63.2° ~ 3.0° |
| Shutter | Automatic /manual,1~1/100000s |
| Through the fog | Adaptive fog |
| Noise-signal ratio | >56dB |
| Wide Dynamic | 120dB |
| Minimal Illumination | 0.003lux(F 1.65,AGC ON,color),0.002lux(F1.65,AG CON,black and white) |
| Switch the mode day and night | Automatic,day,night,switching quantity control |
| 3D positioning | Support |
| Anti-shake | Support |
| Video Frequency | |
| video coding | H.265,H.264,MJPE G |
| Maximum frame rate | 30 Frames |
| Video stream | Main code stream:2688*1520,2560*1440,2304*1296,1920*1080,1280*720(720P),720*576 (D1),640*360,704*288(2 CIF),352*288(CIF); |
| Auxiliary code stream:1920*1080,1280*720(720P),720*576 (D1),640*360,704*288(2 CIF),352* 288(CIF); Third stream:720*576 (D1),640*360,704*288(2 CIF),352*288(CIF) |
|
| Video code rate | 128Kbps~16Mbps |
| OSD | Time,cloud head coordinates,multiplier,preset bit,serial port OSD,number of people statistics,network port OSD,picture OSD,environment volume,device longitude and latitude sitting Standard et al |
| Regional Enhancement (ROI) | Eight areas |
| Privacy cover | Black style,Marseille,gram style:8 single scenes,24 multiple scenes |
| Screenshot | Regular grasp,periodic grasp,cruise preset bit grasp,manual grasp |
| Grasp the map at the maximum resolution | 2688*1520 |
| Audio frequency | |
| Audio encoding format | G.7G11U,G.711A |
| Audio sampling rate | G.711U,G.711A:8KHz /16K Hz |
| Memory | |
| Front end storage | Micro SD,up to 256GB |
| Intelligence | |
| Face detection | Support effect priority,speed priority,cycle preferred three face snap preferred mode,support face Angle filtering; Support human face,human body capture,support human face attribute extraction;Face attributes:gender,age,wearing glasses,wearing masks,hat style,hat color |
| Peripheral cloth defense | Support cross-boundary detection,regional invasion,entry area and leaving area;Support motor vehicles,non-motor vehicles,pedestrian target classification detection,capture and distribution |
| Number of statistics | Statistics of human flow:support the statistics of total number,number of entering and number of leaving,support the three-level alarm of the number of stranded,and clear the statistics of the number of support;Personnel density detection:to support the three-level alarm of personnel density |
| Autotracking | It supports the classification and tracking of motor vehicles,non-motor vehicles and pedestrian targets in the screen,and automatically returns to the original position after reaching the preset tracking time |
| Smart Function | |
| Common event | Motion detection,occlusion detection,sound detection,alarm input,and alarm output |
| Network | |
| Networking protocol | L2TP,IPv4,IPv6,IGMP,ICMP,ARP,TCP,UDP,DHCP,RTP,RTSP,RTMP,DNS,DDN S,NTP ,FTP ,UPnP,HTTP,SNMP,SIP |
| Compatible access | ONVIF Profile G,Profile T ,Profile S,GB/T28181,GA/T 1400,API |
| Cache supplement | Support SD card broken network cache supplementary record |
| Interface features | Description(see the Technical Definition Manual for a detailed description) |
| Interface form | 36pinFFC(including network port,power supply,serial port UART_1,serial port UART_2, Alarm In /0ut,Audio In /Out) |
Use Scenarios
Hazardous Materials Facility Perimeter Monitoring
In chemical plants and refineries, where explosive gases and corrosive substances are present, the explosion-proof and anti-corrosion features of this security camera are critical for compliant perimeter surveillance. It provides high-resolution, long-range zoom capability for detecting unauthorized intrusions and enabling rapid incident response. The AI-powered human and face detection supports comprehensive analytics used by security operators to prioritize threats and streamline workflow through integration with industrial control systems. As a specialized product from a trusted cctv supplier, it meets stringent safety and operational requirements.
Marine and Offshore Platform Surveillance
The camera is well-suited for vessels, offshore drilling rigs, and port facilities requiring continuous security in harsh marine environments with salt corrosion and extreme weather. Its rugged design ensures reliability while the IR and ultra-low illumination capabilities enable effective night monitoring. Integration with maritime surveillance networks is simplified by support for ONVIF and GB/T28181 standards, facilitating remote inspection and asset protection. As a rugged ptz ip camera from professional manufacturers, it enhances security and operational oversight in demanding offshore scenarios.
What materials are used in the construction of your explosion-proof cameras?
Our explosion-proof cameras feature anti-corrosion housings made from special engineering plastics and stainless steel. These materials ensure durability and resistance in harsh, corrosive environments typical in marine, chemical, and industrial settings. This builds reliability into every security camera we supply.
Can you provide customized PTZ IP camera solutions for specific industrial needs?
Yes, we warmly accept ODM and OEM requests. You can customize packaging, logos, and even develop new molds for your unique requirements. Our expertise as a certified cctv supplier allows us to tailor PTZ IP camera solutions that fit diverse hazardous and heavy industrial applications.
How do you handle the installation and integration of your industrial surveillance cameras?
Our cameras support multiple protocols such as ONVIF Profiles G/T/S and GB/T28181, ensuring broad compatibility with existing systems. We provide technical guidance for seamless installation and integration into your industrial network, optimizing your system’s surveillance performance with our reliable security cameras.
What are the shipping options and delivery timeframes for your products?
We partner with major international express carriers like DHL, UPS, FedEx, TNT, and EMS to deliver your orders promptly worldwide. Shipping times vary by destination but we prioritize fast logistics to ensure that your ptz cameras arrive swiftly for your project timelines.
