Name: 4MP 33X-Explosion Proof Anti-Corrosion WDR Starlight PTZ Dome IP Camera
Brand: KAIDUNEX
SKU: KDQ-EX-PTZ403302
Availability: InStock
Rating: 5 (1 reviews)

Description

Specialized Surveillance for High-Risk Environments
Designed for demanding industrial sectors such as petrochemical and hazardous processing plants, this explosion-resistant camera targets professionals requiring uncompromising safety and monitoring precision. Our company provides a solution adaptable to corrosive atmospheres and explosive zones applying internationally recognized standards, offering a robust option within explosion proof camera system solutions. The 360° continuous rotation combined with precise 33X zoom supports comprehensive surveillance, appealing to security engineers and system integrators working in safety-critical facilities.

Advanced Optical and Imaging Performance
The device integrates a 33X optical zoom with fast, accurate autofocus and starlight-level low illumination capability, ensuring clear footage even in near-dark conditions. Its 120dB wide dynamic range improves image clarity in environments with complex lighting contrasts. Strong light suppression and fog compensation technologies enhance visual fidelity under adverse weather. Built-in AI ISP algorithms provide noise reduction while H.265 compression optimizes bandwidth allocation. These technical features comply with the requirements expected from ATEx certified camera technology and deliver reliable data for precise surveillance analysis.

Integration in Rugged Industrial Operations
Our camera supports continuous monitoring in high-risk zones such as oil rigs, chemical plants, and offshore installations. It is engineered to withstand corrosive atmospheres and explosive gases, making it viable for critical infrastructure defense and perimeter inspections. The camera’s face and human body detection functions facilitate automated incident monitoring, enhancing situational awareness within comprehensive explosion proof camera solutions. Its compatibility with ONVIF and GB/T28181 protocols integrates well into existing security networks, streamlining deployment in complex operational environments.

Product Advantages

Structural and Design Advantages for Industrial Safety
The robust enclosure is constructed using corrosion-resistant engineering plastics and stainless steel, reflecting a design optimized for explosive and corrosive conditions as demanded by explosion proof cctv camera system solutions. The modular architecture simplifies installation and maintenance within hazardous zones, while the automatic IR-cut filter supports seamless day-night operation. Precision mechanical components enable smooth 360° panning with minimal wear, ensuring longevity and retrievability of high-definition video essential for strict compliance in explosion proof camera solutions.

Enhanced Performance and Operational Efficiency
This camera delivers superior optical and imaging performance combined with intelligent video analytics such as face and human body detection to reduce false alarms and improve response times. Multi-streaming capability supports simultaneous local recording and remote monitoring without compromising bandwidth efficiency, aligning with industry expectations from explosion proof camera manufacturers. User-configurable on-screen displays and system notifications optimize usability for security personnel, ensuring reliable data capture under challenging industrial conditions.

Specification

Camera
Image device	1/2.7"inch line by line scan 4MP CMOS image sensor
Optical double	33X
Focal distance	Electric and dynamic zoom,4.5~148.5m m
Iris diaphragm	F1.65 (W)~F4.7(T)
Field of View (H)	51.4° ~ 2.5°
Field of View (V)	30.3° ~ 1.4°
Field of View (D)	63.2° ~ 3.0°
Shutter	Automatic /manual,1~1/100000s
Through the fog	Adaptive fog
Noise-signal ratio	>56dB
Wide Dynamic	120dB
Minimal Illumination	0.003lux(F 1.65,AGC ON,color),0.002lux(F1.65,AG CON,black and white)
Switch the mode day and night	Automatic,day,night,switching quantity control
3D positioning	Support
Anti-shake	Support
Detection Distance	105-3100m
Observe Distance	40-1260m
Video Frequency
video coding	H.265、H.264、MJPE G
Maximum frame rate	30 Frames
Video stream	Main code stream:26881520,25601440,23041296,19201080,1280720(720P),720576 (D1),640360,704288(2 CIF),352*288(CIF);
Video stream	Auxiliary code stream:19201080,1280720(720P),720576 (D1),640360,704288(2 CIF),352 288(CIF); Third stream:720576 (D1),640360,704288(2 CIF),352288(CIF)
Video code rate	128Kbps~16Mbps
0SD	Time,cloud head coordinates,multiplier,preset bit,serial port OSD,number of people statistics,network port OSD,picture OSD,environment volume,device longitude and latitude sitting Standard et al
Regional Enhancement (ROI)	Eight areas
Privacy cover	Black style,Marseille,gram style:8 single scenes,24 multiple scenes
Screenshot	Regular grasp,periodic grasp,cruise preset bit grasp,manual grasp
Grasp the map at the maximum resolution	2688*1520
Audio frequency
Audio encoding format	G.7G11U、G.711A
Audio sampling rate	G.711U、G.711A:8KHz /16K Hz
Memory
Front end storage	Micro SD,up to 256GB
Intelligence
Face detection	Support effect priority,speed priority,cycle preferred three face snap preferred mode,support face Angle filtering; Support human face,human body capture,support human face attribute extraction;Face attributes:gender,age,wearing glasses,wearing masks,hat style,hat color
Peripheral cloth defense	Support cross-boundary detection,regional invasion,entry area and leaving area;Support motor vehicles,non-motor vehicles,pedestrian target classification detection,capture and distribution
Number of statistics	Statistics of human flow:support the statistics of total number,number of entering and number of leaving,support the three-level alarm of the number of stranded,and clear the statistics of the number of support;Personnel density detection:to support the three-level alarm of personnel density
Autotracking	It supports the classification and tracking of motor vehicles,non-motor vehicles and pedestrian targets in the screen,and automatically returns to the original position after reaching the preset tracking time
Smart Function
Common event	Motion detection,occlusion detection,sound detection,alarm input,and alarm output
Network
Networking protocol	L2TP、IPv4、IPv6、IGMP、ICMP、ARP、TCP、UDP、DHCP、RTP、RTSP、RTMP、DNS、DDN S、NTP 、FTP 、UPnP、HTTP、SNMP、SIP
Compatible access	ONVIF Profile G、Profile T 、Profile S、GB/T28181、GA/T 1400、API
Cache supplement	Support SD card broken network cache supplementary record
Interface features	Description(see the Technical Definition Manual for a detailed description)
Interface form	36pinFFC(including network port,power supply,serial port UART_1,serial port UART_2, Alarm In /0ut,Audio In /Out)
PTZ
Horizontal Rotation	360°,0.1°/s～200°/s
Vertical Rotation	0°～90°,0.1°/s～120°/s
Preset Position	255,300°/s,±0.5°
General
Power	AC110V-240V,≤40W
Dimensions(LWH)	238312389mm
Net Weight	≤12kg
Material	Stainless Steel 316L
Working Environment	-40℃~60℃,Humidity:≤100%RH(non-condensing)
Strorage Environment	-40℃~60℃,Humidity:s100%RH(non-condensing)
Surge Protection	2KV
Ingress Protection	IP68
Approved
Protectior	IK08(IEC 62262:IP68(IEC 60529-2013)
Explosion protection	ATEX:ll 2G Ex db lIC T6 Gb/ll 2D Ex tb IIIC T80℃Db IP68 IECEx:Ex db lIC T6 Gb/Ex tblIIC T80C Db IP68;For explosive gas atmospheres,the maximum surface temperature is 85℃.Flammable dust atmosphere with a maximum surface temperature of 8°℃;IC:Explosive gas atmospheres other than mine fires;Explosive gas mixture environment:Sector 1,Sector 2,Sector 21,Sector 22.
Verfication to	BS EN 62676-1-1-2014 - Video surveilance systems for use in security applications

Service
You can have the product replaced within 7 days due to quality problem and the quality guarantee period for this product is one year.
You can also get the favorable promotions.
In the following conditions the product is not considered within the quality guaranteescope:
- Client cannot bring forth the quality guarantee card and invoice or receipt of purchasing;
- Improper service conditions,such as unmatched power,ambient temperature,humidity or lightingcaused malfunction;
- Malfunction caused by accident,negligence,disaster incorrect operation or network attack;
- Malfunction or damage in installation,repair,modification or dismantle caused by unauthorizedpersonnel;
- Out of guarantee period.
If you have any dissent on technical service provided by distributor,please lodge acomplaint to the customer's service center of Kaidun.
The quality guarantee card will be validated only after it's stamped by the after-service provider.

Use Scenarios

Perimeter Surveillance in Hazardous Industrial Sites
In petrochemical plants and chemical processing facilities, continuous perimeter surveillance is crucial to detect unauthorized intrusion or operational hazards. This camera’s explosion proof certification ensures safe deployment in zones with flammable gases. Its 33X zoom and 360° rotation enable comprehensive coverage of large areas with precise detail. Integration with centralized security platforms enables real-time alerts and incident recording, supporting compliance with industrial safety protocols mandated by vigilant explosion proof camera manufacturers.

Monitoring Corrosive Offshore Installations
On oil rigs, ships, and offshore platforms exposed to harsh weather and corrosive saltwater atmospheres, reliable visual monitoring is paramount to operational security. The anti-corrosion housing extends service life under these conditions, while adaptive fog and strong light suppression technologies maintain image clarity during adverse weather. The camera seamlessly integrates into maritime security systems, offering continuous 24/7 surveillance aligned with international standards observed in explosion proof camera solutions, facilitating risk mitigation and operational control.

FAQ

What materials are used to ensure the explosion-proof and anti-corrosion properties of the camera?
The camera housing uses special engineering plastics and stainless steel, offering corrosion-resistant and high-temperature resistance suitable for harsh industrial conditions. These materials meet strict standards for explosion-proof camera solutions to ensure durability in volatile environments.

Can the 4MP 33X PTZ Dome IP Camera be customized to specific industrial surveillance needs?
Yes, Kaidun provides tailored options for different site requirements. This includes adaptations for various hazardous zones and integration with existing explosion-proof CCTV camera system solutions, ensuring compatibility and optimized performance for your project demands.

What installation considerations are there for deploying this explosion-proof PTZ camera?
Installation requires compliance with local safety standards for hazardous areas, including proper mounting on stable structures. The camera supports multiple network protocols facilitating easy integration within industrial explosion-proof camera manufacturers’ systems and ensures continuous 360° coverage.

How does Kaidun support maintenance and technical issues for their explosion-proof surveillance products?
Kaidun offers technical support and post-sales services based on years of experience. Maintenance involves recommended cleaning of optical parts and software updates to AI-ISP algorithms for noise reduction, ensuring long-term reliable operation within explosion proof camera applications.
