Type |
KDH-EX-VL404IRW01 |
|
Material |
Stainless Steel 316L |
|
Protection Class |
IP68 |
|
Temp.range min |
-40℃ |
|
Temp.range max |
+60℃ |
|
Video |
IP |
|
Operational Areas |
Outdoor |
|
Mounting |
Wall mounted,column etc |
|
Wiper/IR |
Wiper/IR |
|
Infrared Distance |
100-150m |
|
Resolution |
4MP（2560*1440） |
|
Zoom |
2.8~12mm,4x optical zoom |
|
Image Sensor |
1/1.8’’Progressive scan CMOS |
|
Min.illumination |
Color:0.005lux@(F1.6,AGC ON),Black and white:0.0005lux@(F1.6,AGC ON) |
|
Functions |
Anti-Flicker,heartbeat,password protection,Privacy mask,watermark |
|
Voltage |
DC12V/POE/DC24V/AC24V/POE+/AC100-240V power optional |
|
Weight |
≤8KG |
|
Dimensions(L*W*H) |
428*183*241mm |
|
Certificates |
BS EN62676-1-1-2014 |
|
Explosion Proof Mark |
Ex ll 2G Ex db op is IIC T6 Gb II 2D Ex tb op is IIIC T80℃ Db IP68 IP66 |
