Type |
KDH-EX-VL822(IRW)01 |
|
Material |
Stainless Steel 316L |
|
Protection Class |
IP68 |
|
Temp.range min |
-40℃ |
|
Temp.range max |
+60℃ |
|
Video |
IP |
|
Operational Areas |
Outdoor |
|
Mounting |
Wall mounted,column etc |
|
Starlight |
Built-in AI ISP algorithm,intelligent noise reduction,restore the wonderful horizon under the low light |
|
Surge Protection |
2KV |
|
Resolution |
8MP(3840*2160) |
|
Zoom |
6.5-143mm,22x optical zoom |
|
Image Sensor |
1/1.8’’Progressive scan CMOS |
|
Min.illumination |
Color:0.03lux@(F1.5,AGC ON),0 lux(infrared enabled) |
|
Functions |
Anti-Flicker,heartbeat,password protection,Privacy mask,watermark |
|
Voltage |
DC12V/POE/DC24V/AC24V/POE+/AC100-240V power optional |
|
Weight |
≤5KG |
|
Dimensions(L*W*H) |
428*140*144.5mm |
|
Certificates |
BS EN62676-1-1-2014 |
|
Explosion Proof Mark |
Ex ll 2G Ex db op is IIC T6 Gb II 2D Ex tb op is IIIC T80℃ Db IP68 IP66 |
