This explosion proof camera is engineered for demanding conditions, targeting industrial operators requiring reliable monitoring in hazardous zones. Its anti-corrosion stainless steel 316L housing and IP68 rating ensure durability against water, dust, and chemical exposure. Designed for offshore platforms, chemical plants, and industrial yards, it provides a secure security surveillance camera option compliant with stringent safety requirements while facilitating integration into comprehensive cctv camera solutions for critical infrastructure protection.
Advanced Imaging Performance and Technical Specifications
Equipped with an 8MP 1/2.7” CMOS sensor, the camera delivers up to 3840x2160 resolution at 20 fps, supporting Ultra 265, H.265, H.264, and MJPEG codecs for efficient bandwidth management. Its 120dB true WDR and Easystar low-light technology assure clear imaging even in high-contrast or low illumination areas. With IR illumination up to 30 meters, Day/Night switching via IR-cut filter, and flexible lens options (2.8mm and 4.0mm), this industrial camera provides precise visual detail. PoE and DC 12V power inputs support versatile installation, while the ONVIF and SDK compatibility facilitates seamless integration with existing industrial surveillance cameras systems.
Versatile Deployment Across High-Risk Industries
The camera's explosion proof and anti-corrosion features make it ideal for deployment in oil and gas fields, marine vessels, chemical facilities, and offshore rigs, where exposure to corrosive elements and explosive atmospheres is common. Its rugged design withstands temperature extremes from -40°C to 60°C and high humidity, supporting 24/7 perimeter monitoring and operational surveillance. By integrating into complex security surveillance camera networks, it enhances situational awareness and risk mitigation in sectors requiring robust, safe, and corrosion-resistant cctv camera solutions.
Structural and Design Innovations for Challenging Environments
This explosion proof camera features precision-engineered stainless steel 316L housing combined with an IP68 ingress protection rating, ensuring exceptional resistance to corrosion, dust, and water ingress. The compact bullet form factor allows flexible mounting in confined or vertical spaces, supported by 9:16 Corridor Mode. Modular video codec support and multiple power input options such as PoE and DC make it compatible with diverse industrial camera systems. The design also incorporates surge protection rated at 2KV for electrical safety, underlining its suitability for hazardous environments and integrating effortlessly into large-scale industrial surveillance cameras deployments.
Enhanced Performance and Integration Value for Users
Performance-wise, the camera balances high-resolution output with efficient data compression, resulting in optimal network bandwidth use suited for advanced security surveillance camera systems. The 120dB true WDR and Smart IR provide superior image clarity under challenging lighting and nighttime conditions, reducing false alarms and enhancing threat detection accuracy. Its broad operating temperature and humidity tolerance make it operationally reliable. Support for ONVIF, API, and SDK promotes interoperability and customization, facilitating management across multi-vendor cctv camera solutions platforms, thereby increasing overall system operational efficiency and return on investment.
| Camera | ||||||||
| Sensor | 1/2.7",8.0 megapixel,progressive scan,CMOS | |||||||
| Minimum llumination | Support Easystar:Colour:0.005 lux(F1.6,AGC ON) OLuxwith IR on |
|||||||
| Day/Night | IR-cut filter with auto switch (ICR) | |||||||
| Shutter | Auto/Manual,1~1/100000 s | |||||||
| Adjustment angle | Pan:0°~360° | Tilt:0°~90° | Rotate:0°~360° | |||||
| S/N | >56dB | |||||||
| WDR | 120dB | |||||||
| Lens | ||||||||
| Lens Type | 2.8mm @F1.6 | 4.0mm @1.6 | ||||||
| Iris | Fixed | |||||||
| Field of View(H) | 98.3° | 91.2° | ||||||
| Field of View (V) | 53.3° | 47.9° | ||||||
| Field of View (D) | 103.1 | 95.9° | ||||||
| DORI | ||||||||
| DORI Distance | Lens | Detect(m) | Observe(m) | Recognize(m) | Identify(m) | |||
| 2.8mm | 84 | 33.6 | 16.8 | 8.4 | ||||
| 4.0mm | 120 | 48 | 24 | 12 | ||||
| Illuminator | ||||||||
| IR Range | Up to 30m IR range | |||||||
| Wavelength | 850nm | |||||||
| IR On/Off Control | Auto/Manual | |||||||
| Video | ||||||||
| Video Compression | Ultra 265,H.265,H.264,MJPEG | |||||||
| H.264 code profile | Baseline Profile,Main Profile,High Profile | |||||||
| Frame Rate | Main Stream:8MP (3840*2160),Max 20fps;5MP(3072*1728),Max 30fps;4MP(2560*1440),Max 30fps;1080P (1920*1080),Max 30fps; Sub Stream:1080P(1920*1080),Max 30fps;720P(1280*720),Max30fps;D1(720*576),Max 30fps;640*360,Max 30fps; 2CIF(704*288),Max 30fps;CIF(352*288),Max 30fps; |
|||||||
| Video Bit Rate | 128 Kbps~16 Mbps | |||||||
| U-code | Support | |||||||
| OSD | Up to 4 OSDs | |||||||
| Privacy Mask | Up to 4areas | |||||||
| ROI | Up to 8 areas | |||||||
| Video stream | Dual streams | |||||||
| Image | ||||||||
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 | |||||||
| Digital noise reduction | 2D/3D DNR | |||||||
| Smart IR | Support | |||||||
| Flip | Normal/Vertical/Horizontal/180°/90℃lockwise/90Anti-clockwise | |||||||
| HLC | Supported | |||||||
| BLC | Supported |
| Defog | Digital Defog |
| Events | |
| Basic Detection | Cros line,intrusion(based on human body detection),motion detection,UIltra motion detection,tampering alarm,audio,detection |
| General Function | Watermark,IP address filtering,access policy,ARP protection,RTSP authentication,user authentication,HTTP authentication |
| Storage | |
| Edge Storage | Micro SD,up to 256GB |
| Network Storage | ANR,NAS(NFS) |
| Network | |
| Protocols | IPv4,IPv6,IGMP,ICMP,ARP,TCP,UDP,DHCP,RTP,RTSP,RTCP,DNS,DDNS,NTP,FTP,UPnP,HTTP,HTTPS,SMTP,SSL/TLS,QoS,802.1x,SNMP |
| CompatibleIntegration | ONVIF (Profile S,Profile G,Profile T),API,SDK |
| User/Host | Up to 32 users.2 user levels:administrator and common user |
| Security | Password protection,Strong password,HTTPS encryption,Export operation logs,Basic and digest authentication for RTSP,Digest authentication for HTTP,TLS 1.2,WSSE and digest authentication for ONVIF |
| General | |
| Power | DC 12V±25%,POE(IEEE 802.3af),≤8W (The maximum power supply distance of POE is 80m) |
| Dimensions(L*W*H) | 141*104*124mm |
| Net Weight | ≤2.4kg |
| Material | Stainless Steel 316L |
| Working Environment | -40°C~60°C,Humidity: ≤100% RH(non-condensing) |
| Strorage Environemnt | -40°C~60°C,Humidity: ≤100% RH(non-condensing) |
| Surge Protection | 2KV |
| Ingress Protection | IP68 |
What materials are used in your explosion proof industrial cameras?
We use stainless steel 316L for the housing of our explosion proof camera, ensuring excellent corrosion resistance and durability. This material withstands harsh industrial environments including chemical exposure, making it ideal for reliable long-term surveillance.
Can you customize the camera to fit specific industrial surveillance needs?
Yes, we offer ODM and OEM services for our industrial surveillance cameras. You can customize packaging, logos, and even product specifications. Our team is ready to support your unique project requirements with tailor-made security surveillance camera solutions.
How difficult is it to install the 8MP explosion proof camera in hazardous locations?
Our camera supports PoE and DC 12V power options for flexible installation. It complies with ONVIF standards, allowing integration into existing CCTV camera solutions easily. We also provide APIs and SDKs for advanced system compatibility to suit your industrial setup.
What shipping and payment options do you offer for bulk industrial camera orders?
We cooperate with international express companies such as DHL, FedEx, UPS, and TNT to deliver your industrial camera orders promptly. We accept multiple payment methods including T/T, L/C, and Western Union to ensure smooth transactions tailored to your business needs.
