Designed for hazardous environments, this 8MP explosion-proof PTZ mini dome camera offers precise monitoring with a 4X motorized lens, AI detection, and IP66 rating. Ideal for reliable surveillance cameras for business and industrial use.
Targeted Solutions for High-Risk Surveillance
The 8MP Explosion Proof Anti-Corrosion PTZ IR Mini Dome Camera addresses the critical need for robust security in hazardous and corrosive environments. Engineered for industrial users such as chemical plants, offshore platforms, and refineries, this security surveillance camera supplier provides a device capable of continuous operation in ignition-risk zones. Its construction complies with explosion-proof standards and anti-corrosion requirements, ensuring safety and durability where traditional surveillance cameras would fail. This product suits businesses that demand compliance, reliability, and integration flexibility for hazardous area monitoring.
Advanced Optical and Network Technology
Featuring an 8MP Sony CMOS sensor and a 4X motorized lens with a 2.8-12mm focal range, this camera delivers detailed, adaptable imaging suitable for various monitoring distances and angles. The device supports pan 0–355° and tilt 0–90° movement at high speeds, enhancing situational awareness. Key imaging features include D-WDR, 3D noise reduction, and IR illumination up to 40 meters for clear night vision. Compatibility with ONVIF 17.2 Profile S and multiple network protocols ensures seamless integration with existing NVRs and CMS software platforms managed by cctv camera suppliers. Power options include 12V DC and PoE, optimizing installation configurations.
Industrial Applications with Operational Benefits
Deployed in hazardous zones and corrosive settings, this security surveillance camera supplier excels in perimeter security, emergency scene management, and offshore platform monitoring. Its explosion-proof certification and IP66 ingress protection guarantee functional resilience in petroleum, chemical, and maritime sectors. The device’s AI-based human and vehicle detection capability enhances proactive threat identification, reducing false alarms and operational costs. By integrating effectively into industrial safety systems, it provides key insights for risk mitigation and compliance, thereby increasing operational security ROI for surveillance cameras for business environments in stringent conditions.
Product Advantages
Structural and System Design Excellence
This surveillance camera reflects advanced design principles from leading security camera suppliers, combining explosion-proof housing with anti-corrosion materials to ensure longevity in harsh conditions. The modularized PTZ mechanism allows precise control over the 0–355° pan and 0–90° tilt range, facilitating comprehensive area coverage with up to 16 preset positions. Its IP66-rated enclosure protects against dust and water ingress, making it ideal for outdoor installations in corrosive or maritime climates while maintaining compliance with industry safety standards crucial to cctv camera suppliers focusing on industrial-grade security.
Optimized Performance and User Efficiency
The camera’s integration of AI-driven detection algorithms for humans and vehicles enables enhanced security intelligence, minimizing false alarms and improving incident response times. With video compression standards like H.265 and multiple streaming capabilities, it reduces bandwidth usage while maintaining high-quality footage. Power options, including PoE, simplify deployment and reduce infrastructure costs. The device’s ease of integration with ONVIF-compatible systems ensures interoperability across multiple security platforms favored by security camera suppliers, offering end-users scalable and reliable surveillance solutions tailored to complex environmental demands.
| Camera | |
| Image Sensor: | 1/2.8"Sony415 8MP CMOS |
| Signal System: | PAL/NTSC |
| Min. Illumination: | Color: 0.05lux @(F1.2, AGC ON), 0 lux with IR |
| Shutter Time: | 1/25 s to 1/10,000 s |
| Lens: | 4X 2.8-12mm Motor Lens |
| Day&Night: | IR cut filter with auto switch |
| Image Enhancement: | BLC/3D DNR/D-WDR |
| Motion Detection | Support |
| Intelligent Detection(AI) | Human Detection,Vehicle detection |
| Privacy Protection | Support(4 Self-customized Areas) |
| Wather-Proof: | IP66 |
| Illumination for Infrared Switching: | 0.5~3Lux |
| Infrared Wavelength: | 850nm |
| Mimimum Illumination: | 0 Lux(IR ON) |
| IR Range: | 2pcs LEDs//35m IR |
| Compression Standard | |
| Video Compression: | H.265/H.264/MJPEG |
| Video Bit Rate: | 128Kbps~12Mbps(main stream H.265) 64kbps~1024kbps(sub stream H.265) 64kbps~1024kbps(thr stream H.265) |
| Audio Compression: | G711U/G711A |
| Dual Streams: | Yes |
| Triple Streams: | Yes |
| Image | |
| Max. Image Resolution: | 3840*2160(8MP)@20fps |
| Frame Rate: | 20fps(8MP).MAX main stream 30fps（D1) .MAX sub stream 10fps（FHD).MAX thr stream |
| Image Settings: | 3D NR, D-WDR, Image Flip, Saturation, Brightness, Contrast, Sharpness adjustable via client software, web browser or Smartphone App |
| Day/Night Switch: | EXT/Day/Night/Auto/Time |
| Audio | |
| Line IN/line OUT: | Support（1ch） |
| Build-in MIC: | Optional |
| Volnume adject: | yes |
| Network | |
| Network Protocols: | HTTP, TCP/IP, IPv4/v6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS,RTMP,IP Search(Support P2P, NVR, NVS etc.) |
| System Compatibility: | ONVIF(17.2 with profile S) |
| On-line Viewing | Max. Support 2 Users Simultaneously |
| Interface | |
| Communication Interface: | 1 RJ45 10M / 100M Ethernet Interface |
| RCA Audio Interface: | RCA Audio input/output Interface (Optional) |
| Alarm in/out interface: | Support（1ch） （Optional） |
| DC Power Plug: | DC Power Femate Interface |
| PTZ | |
| Angle: | Pan:0~355° / Tilt:0~90° |
| speed: | Pan: about 35°/s / Tilt: about 35°/s |
| preset: | support 16 preset |
| General | |
| Operating Conditions: | -40 °C ~ 60 °C |
| Humidity 95% or less (non-condensing) | |
| Power Supply: | 12 V DC ± 10%/PoE(Optional) |
| Power Consumption: | 12 VDC ± 10%, Max Power Comsumption Less than 8W (When the infrared lamps turn on) |
| Weight: | 4KG |
| Verification to | BS EN62676-1-1-2014-Video surveillance systems for use in security applications |
Use Scenarios
Hazardous Industrial Zone Surveillance
In chemical plants and oil refineries, safety monitoring must comply with strict explosion-proof regulations. This 8MP PTZ mini dome camera provides essential surveillance capabilities by capturing high-resolution imagery with a motorized zoom lens and rapid pan-tilt control, facilitating real-time monitoring of large and potentially volatile zones. Its anti-corrosion and IP66 protections ensure continuous operation amid chemical fumes and moisture. Integrated AI detection enhances operational security by distinguishing authorized personnel and vehicles from potential threats, enabling security teams to swiftly react within critical infrastructure workflows supported by trusted cctv camera suppliers.
Marine and Offshore Platform Monitoring
Marine installations and offshore rigs operate under demanding environmental conditions that necessitate durable surveillance cameras for business continuity and safety assurance. This explosion-proof security surveillance camera withstands salt spray, wind, and humidity with its sealed stainless steel and anti-corrosion design. The camera’s IR illumination capability allows for effective nighttime surveillance while maintaining compliance with maritime safety protocols. Network compatibility enables seamless integration into centralized monitoring systems, offering offshore safety managers a robust solution for vessel and platform security, anomaly detection, and regulatory compliance critical to maritime-focused security camera suppliers.
What makes your explosion-proof cameras suitable for hazardous environments?
Our security surveillance cameras feature explosion-proof and anti-corrosion construction certified for use in ignition-risk zones. They meet IP66 standards and withstand corrosive and high-temperature conditions, ensuring reliable operation in hazardous industrial settings such as chemical plants and offshore rigs.
Can I customize the camera system for specific industrial needs?
Yes, we offer full ODM and OEM customization, including packaging, logo branding, and specialized designs for unique applications. Our production team supports tailored solutions to meet exact surveillance requirements, making us a leading security camera supplier for industrial and marine sectors.
How do you ensure compatibility with existing surveillance systems?
Our cameras support ONVIF 17.2 Profile S, RTSP, and multiple network protocols, ensuring seamless integration with a wide range of NVRs and CMS platforms. This flexibility guarantees smooth deployment and operation within your current surveillance infrastructure.
What options exist for camera installation and power supply?
The 8MP.4X Explosion Proof Anti-Corrosion PTZ IR Mini Dome Camera supports both 12V DC and Power over Ethernet (PoE) power options for versatile installation. We provide guidance for setup in tough environments, assuring stable performance for your surveillance business needs.
