Functional Scope Tailored for Hazardous Environments
Designed for industrial safety managers and security engineers, this camera serves critical surveillance needs in explosion-risk and corrosive areas. As a product from experienced explosion proof camera manufacturers, it addresses stringent compliance requirements with ATEx and explosion-proof certification. It integrates seamlessly into explosion proof cctv camera system solutions, providing dual-spectrum imaging to accommodate diverse monitoring tasks. This solution caters to petrochemical plants, offshore rigs, and chemical processing facilities where continuous, reliable observation is paramount to operational safety.
Advanced Imaging and Technical Specifications for Precision Monitoring
Equipped with a cutting-edge 12μm infrared detector, this ATEx certified camera delivers enhanced image clarity and extended detection range. The 360° continuous horizontal and ±90° vertical rotation capabilities ensure full coverage without blind spots. The durable 304/316L stainless steel housing with IP68 rating and explosion-proof certification guarantees functionality in corrosive and hazardous conditions. Integration with ONVIF-compliant NVR systems and provision of an SDK enable flexible deployment and custom application development within broader explosion proof camera solutions frameworks.
Industrial Applications Demonstrating Practical Security Value
This explosion proof camera system solution has proven utility in environments such as offshore oil platforms, chemical plants, and marine installations. Its fire detection and intelligent intrusion analytics support proactive hazard mitigation strategies. By combining thermal and optical data streams, operators can detect temperature anomalies and unauthorized access efficiently. The camera also withstands harsh weather thanks to automotive-grade wipers, sustaining operational integrity in extreme conditions—making it a vital asset in industrial safety and security ecosystems.
Product Advantages
Design and Structural Benefits Optimized for Harsh Conditions
The robust construction featuring corrosion-resistant stainless steel and compliance with Exd IC T6 Gb standards reflect a deliberate design to endure explosive and corrosive atmospheres. The system benefits from modular camera architecture facilitating straightforward integration into existing security infrastructures. The dual-spectrum mechanism maximizes situational awareness by leveraging both thermal and visible imaging inputs. Moreover, the camera’s IP68 encapsulation rating ensures ingress protection against dust and water, consolidating its position within effective explosion proof camera solutions.
Operational Performance Enhancing Security Monitoring Efficacy
This device delivers superior usability through adjustable rotation speeds and intelligent video analytics, including intrusion and cross-line detection that reduce false alarms. The combination of thermal and visible spectrums advances situational comprehension during day and night shifts. Compatibility with industry-standard communication protocols and secondary development SDKs supports customized applications, thereby enhancing user value. Such features enable security teams to maintain vigilant surveillance with optimized resource allocation and increased system reliability in hazardous operations.
Specification
| Thermal |
| Sensor Type |
VOx uncooled FPA detector |
| Spectral Range |
8~14μm |
| NETD |
≤40mK(@25°C,F#1.0,25Hz) |
| Max.Resolution |
640*512 |
| Pixel Pitch |
12μm |
| Focal Length |
13mm |
25mm |
| Focus Mode |
Fixed,motorized focus |
| FOV |
33°×26° |
17.5°×14° |
| F number |
F1.0 |
| Spatial Resolution |
0.92mrad |
0.480mrad |
| Color Palettes |
20 modes selectable such as
Blackhot/Whitehot/Rainbow,etc. |
| Visible |
| Image sensor |
1/1.8inch 4MP CMOS |
| Max.Resolution |
2688×1520 |
| Focal Length |
6.5mm~130mm |
| Focus Mode |
Auto/Manual/Semi-auto |
| FOV |
59.6°×35.9°~3.2°×1.8° |
| WDR |
≥55dB |
| Day /Night |
ICR |
| Defog |
Support optical defog |
| PTZ |
| Pan Range |
360°continuous |
| Pan Speed |
0.1°~40°/s |
| Tilt Range |
-90°~+90° |
| Tilt Speed |
0.1°~40°/s |
| Scan Mode |
Preset/Tour/Scan Patrol/Linear Scan/Pattern |
| Network |
| Protocols |
TCP/IP,UDP,ICMP,HTTP,HTTPS,FTP,DHCP,DN
S,RTP,RTSP,RTCP,IGMP,SMTP,NTP,QoS |
| Interoperability |
ONVIF/GB28181/SDK |
| Simultaneous live view |
Up to 20 channels |
| User Management |
Up to 20users,2 levels:Administrator and User |
| Browser |
Support IE,Edge,Chrome,Firefox,and other
browsers |
| Video |
| Max.Resolution |
2688×1520 (Visible) 1280×1024(Thermal) |
| Image Encoding |
JPEG |
| Format |
|
| Audio Compression |
G.711A/G.711Mu/PCM/AAC/MPEG2-Layer2 |
| Video Compression |
H.264/H.265/MJPEG |
| Main Stream |
Visible:50Hz:25fps(2688×1520,1920×1080,1280×720)
60Hz:30fps(2688×1520,1920×1080,1280×720)
Thermal:50Hz:25fps(1280×1024,1280×720,1024×768) |
| Sub Stream |
Visible:50Hz:25fps(1920×1080,1280×720,704×576,352×288)
60Hz:30fps(1920×1080,1280×720,704×480,352×240)
Thermal:50Hz:25fps(640×512,384×288) |
| Temperature Measurement |
| Measurement Range |
-20℃~+550℃ |
| Measurement Accuracy |
±2℃ or ±2%,the larger value shall prevail |
| Measurement Analysis |
Temperature measurement tools(Global,Point,Line,Area)and linkage alarm |
| Smart Function |
| Fire Detection |
Yes |
| Smart Record |
Alarm trigger recording,disconnection trigger recording |
| Smart Alarm |
Support alarm trigger of network disconnection,IP address conflict,full memory,memory error,illegal access and burn |
| VCA |
Cross line detection,intrusion detection |
| Alarm Linkage |
Recording/lmage capture/Sending Email/PTZ linkage/Alarm output |
| System Interface |
| Power Supply |
AC85V~260V |
| Communication Interface |
RJ45 self-adaptive 10M/100M Ethernet port |
| Storage Interface |
Support Micro SD card (Max.256G) |
| RS485 |
1 channel |
| The recommended distance of detecting, recognizing and identifying for man (1.8×0.5m) and vehicle(1.4×4.0m) are as follows: |
| Lens |
DD
(Vehicle) |
DD
(Man) |
RD
(Vehicle) |
RD
(Man) |
ID
(Vehicle) |
ID
(Man) |
| 13mm |
1661m |
542m |
415m |
135m |
208m |
68m |
| 25mm |
3194m |
1042m |
799m |
260m |
399m |
130m |
| General |
| Power |
AC100V-240V ,≤75W |
| Dimensions(L*W*H) |
436*296*406mm |
| Net Weight |
≤26kg |
| Material |
Stainless Steel 316L |
| Working Environment |
-40℃~60℃,Humidity:≤100%RH(non-condensing) |
| Strorage Environment |
-40℃~60℃,Humidity:s100%RH(non-condensing) |
| Surge Protection |
2KV |
| Ingress Protection |
IP68 |
| Inlet Hole Specification |
1 Entry hole G3/4 |
| Installation Method |
Wall or column platform installation |
| PTZ |
| Rotation Angel |
Horizontal:0°-360°
Vertical:-90°-+90° |
| Approved |
| Protectior |
IK08(IEC 62262:IP68(IEC 60529-2013) |
Explosion
protection |
ATEX:ll 2G Ex db lIC T6 Gb/ll 2D Ex tb IIIC T80℃Db IP68 IECEx:Ex db lIC T6 Gb/Ex tblIIC T80C Db IP68;For explosive gas atmospheres,the maximum surface temperature is 85℃.Flammable dust atmosphere with a maximum surface temperature of 8°℃;IC:Explosive gas atmospheres other than mine fires;Explosive gas mixture environment:Sector 1,Sector 2,Sector 21,Sector 22. |
| Verfication to |
BS EN62676-1-1-2014- Video surveillance systems for use in security applications |
Service
You can have the product replaced within 7 days due to quality problem and the quality guarantee period for this product is one year.
You can also get the favorable promotions.
In the following conditions the product is not considered within the quality guaranteescope:
- Client cannot bring forth the quality guarantee card and invoice or receipt of purchasing;
- Improper service conditions,such as unmatched power,ambient temperature,humidity or lightingcaused malfunction;
- Malfunction caused by accident,negligence,disaster incorrect operation or network attack;
- Malfunction or damage in installation,repair,modification or dismantle caused by unauthorizedpersonnel;
- Out of guarantee period.
If you have any dissent on technical service provided by distributor,please lodge acomplaint to the customer's service center of Kaidun.
The quality guarantee card will be validated only after it's stamped by the after-service provider.
Use Scenarios
Surveillance in Offshore Oil and Gas Platforms
Within offshore petroleum environments, the camera functions as a critical node for continuous safety surveillance, detecting explosive gases and environmental hazards. Its corrosion-resistant stainless steel body withstands saline and harsh marine conditions, supporting longevity in challenging atmospheres. The ATEx certified camera meets stringent industry standards, ensuring compliance with safety regulations while enabling integration into centralized monitoring NVR systems. This capability enhances incident response times and supports regulatory inspection protocols in high-risk zones.
Fire and Intrusion Monitoring in Chemical Processing Plants
Used in chemical manufacturing facilities prone to volatile reactions, the camera operates to detect signs of fire and unauthorized access through advanced thermal and visible imaging. Its smart fire detection algorithms provide early alerts to mitigate industrial accidents. The explosion proof cctv camera system solutions allow seamless networking into existing security infrastructure, enabling real-time monitoring and temperature-based safety controls. The durable design affords reliable operation in corrosive atmospheres, fulfilling safety compliance and operational continuity in chemical production environments.
FAQ
What materials are used in the construction of the explosion proof camera?
This explosion proof camera features a corrosion-resistant stainless steel body made from 304/316L grades, combined with an IP68 encapsulation rating to ensure durability and safety in hazardous and corrosive environments. These materials support long-term reliability in industrial settings.
Can the explosion proof camera be customized for specific industrial needs?
Yes, our cameras support secondary development through their provided SDK, allowing integration and customization to fit specific applications. We specialize in explosion proof camera solutions tailored to sectors like petroleum, chemical, and offshore industries, ensuring compliance and operational efficiency.
What installation environments are suitable for this explosion proof cctv camera system?
The system is designed for high-risk sites such as chemical plants, offshore platforms, and areas with corrosive atmospheres. Its explosion-proof certification and anti-corrosion design make the explosion proof CCTV camera system solutions ideal for safety-critical industrial monitoring, including temperature and fire detection.
How is maintenance managed for the dual-spectrum PTZ IP camera?
Maintenance involves regular inspection of the stainless steel housing and the automobile-grade wiper, which ensures clear optical performance in adverse weather. The camera’s robust design minimizes downtime, supporting continuous operation in harsh environments, which is essential for explosion proof camera manufacturers aiming for long-term reliability.
