Technical Parameters
| Material | Stainless Steel 316L |
| Protcetion Class | IP68 |
| Temp.range min | -40℃ |
| Temp.range max | +70℃ |
| Video | IP |
| Operational Areas | Outdoor |
| Mounting | Wall mounted,Column Installation |
| Surface | Powder coating or electric polishing |
| IR Range | 100m(300m optional) |
| Thermal Resolution | 256*192/384*288/640*512/1280*1024 etc |
| Thermal Focal Length | 4.1mm/6.9mm/9mm /13mm/19mm/25mm/35mm/50mm etc |
| Optional Matching Scheme | Starlight-level Lens / Gyriscope/Observation-type Thermal/TemperatureMeasurement-type Thermal/Anti-Flicker,heartbeat,passwordprotection,Privacy mask,watermark |
| Voltage | DC24V/POE++/AC100-240V power optional |
| Weight | ≤24.2kg |
| Dimensions(L*W*H) | 334*290*407mm |
| Ex Grade | Ex db I Mb Ex db IIC T6 Gb,Zone 1&2 Ex tb ⅢIC T85'℃ Db,Zone 21&22 |
| Certificates | IECEX ATEX Certification Body:DNV |
Application Scenarios
Other application areas:desert drill sites,offshore rigs,mechanical engineering,biogas plants,military,electric power,hydraulic power,railway,metallurgy,natural gas extraction,drilling platform,aerospace,marine,armed police,border defense,vessels,fireworks production,ports etc.
