■EX Certification:IECEx/ATEX/DNV
■EX Grade:Ex dIIC T6 Gb,Zone 182;Ex tb IIIC T85℃ Db,Zone 21&22
■ Gear transmission and worm gear transmission methods are available.
■ Electro-polished AISI 316L stainless steel
■ Germanium Glass &Tempered Glass
■ Ingress Protection Rating:IP68
■ Ambient Temperature:-40℃~+70℃
■ Pan/Tilt Speed:0.1°~45°sec(Max 45°/sec)
■ Pan Rotation Angle:360°Endless,Tilt Rotation Angle:±90°
■640X512 Thermal Camera/2MP38xOptical Zoom Camera(4MP/5MP/6MP/8MP etc resolution optional,22x/33x/38x etc Zoom optional)
■ Gas detection:Working bandwidth 3.0μm~3.5μm
■IR Range:150m(300m optional)
Technical Parameters
| Material | Stainless Steel 316L |
| Protection Class | IP68 |
| Temp.range min | -40℃ |
| Temp.range max | +70℃ |
| Vibration(0-100Hz) | 0.7g |
| Video | IP |
| Operational Areas | Outdoor |
| Mounting | Wall mounted,column etc |
| Wiper/IR | Wiper/IR |
| Pan/Tilt | Remote operated |
| Rotation Vertical | ±90° |
| Rotation Horizontal | 360° |
| Surface | powder coating or electric polishing |
| Resolution | 2MP,3MP,4MP,5MP,8MP etc |
| Zoom | 20x,33xetc |
| CCTV add-on | Gas detcetion with temperature measurement |
| Temperature measurement range | -20℃~+550℃ |
| Voltage | DC24V/POE++/AC100-240V power optional |
| Weight | ≤30kg |
| Certificates | IECEX ATEX Cerfication Body:DNV |
| EX Mark | Ex db I Mb Ex db IIC T6 Gb,Zone 1&2 Ex tb ⅢIC T85'℃ Db,Zone 21&22 |
Application Scenarios
Other application areas:desert drill sites,offshore rigs,mechanical engineering,biogas plants,military,electric power,hydraulic power,railway,metallurgy,natural gas extraction,drilling platform,aerospace,marine,armed police,border defense,vessels,fireworks production,ports etc.
